Each solar panel includes standard solar connectors that extend from the junction box affixed to the back of each panel
Easy installation and handling for various applications: 14 pre-drilled holes compatible with ground mounts, Z-brackets, pole mounts and tilt mounts, and compatible with on-grid and off-grid inverters
Excellent low light performance on cloudy days, mornings and evenings; certified to withstand challenging environmental conditions
Built with strong high transmission anti-reflective coated tempered glass and anodized aluminum frame
High Transmission, AR (anti-reflective) Coated Tempered Glass
Plug and play junction box
Industry standard quick connect cables work in series or in parallel
Certified to withstand challenging environmental conditions
Excellent low light performance on cloudy days, mornings and evenings
Installation
Easy installation and handling for various applications (high-end off-grid and mobile applications)
Pre-drilled holes compatible with ground mounts, Z brackets, pole mounts and tilt mounts
Compatible with on-grid and off-grid inverters
Warranty
25 year limited power output
Built-in Components
RICH SOLAR 200 watt monocrystalline solar panel
Panel leads (pair): 3 feet each
IP65 rated waterproof junction box
IP67 rated waterproof solar connectors
Bypass diodes built-in the junction box
Specifications
Maximum Power(Pmax): 200W
Maximum Power Voltage(Vmp): 37.6V
Maximum Power Current(Imp): 5.36A
Open Circuit Voltage(Voc): 45.4V
Short Circuit Current(Isc): 5.83A
Maximum System Voltage(Vmax): 1000VDC
Temperature Range: -40°C ~ 90°C
Max Series Fuse Rating: 15A
Weight: 26.5 lbs
Dimensions: 58.7 x 26.8 x 1.4 in
Additional information
Be Advised: Weight and Dimensions listed in this section may include packaging for shipping purposes. If you need exact weight and dimensions of this product, first review the product description and datasheet. If you are unable to locate these specs, please call our team at 720-594-5272.
